Description
The aluminum alloy flap garage door is crafted from high-end aluminium alloy profiles — bright in colour, elegant in form, and rigorous in structure.
The aluminium surface offers a range of electrostatic powder-coated finishes: wood grain, silver white, and brushed gold. The surface is delicate and smooth with a warm, fade-resistant colour. The coating is strong and does not peel off, delivering excellent anti-corrosion and anti-rust performance.
Product Highlights
Intelligent system design, luxurious and convenient enjoyment.
Aluminum alloy and glass have a human like structure that matches and matches.
The material selection is environmentally friendly, durable, and has a long lifespan that can be recycled.
Flat-panel colour-coated steel garage door
| Item | Specification |
| Material | 0.6 mm galvanised colour-coated steel sheets (both sides) |
| Colour Options | 7024 Charcoal Grey, 7016 Dark Grey, 7011 Medium Grey, Black, White |
| Process | Cutting, Punching, Foaming |
| Material Thickness | 0.6 mm (both sides) |
| Total Door Panel Thickness | 40 mm |
| Hinge Locations | Reinforcing plates embedded for secure hinge installation |
| Bottom Sealing | Rubber sealing strips fitted at the bottom of each door panel section |
| Optional Skylight | Aluminium alloy tempered glass skylight (opening type) |
Colour-coated steel square sections
| Item | Specification |
| Material | 0.35 mm galvanised colour-coated steel sheets (both sides) |
| Colour Options | White, Black, Light Grey, Dark Grey, Wood Grain |
| Process | Cutting, Punching, Foaming |
| Material Thickness | 0.35 mm (both sides) |
| Total Door Panel Thickness | 40 mm |
| Hinge Locations | Embedded backing plates for secure hinge installation |
| Bottom Sealing | Rubber sealing strips fitted at the bottom of each sectional door panel |
| Optional Skylight 1 | Aluminium alloy tempered glass skylight (opening type) |
| Optional Skylight 2 | PC (polycarbonate) skylight (opening type) |
